FD2

5" Top Assembly Adjustable Floor Drain with Deck Plate

Retrofit

Zurn FD2 Floor Drain with PVC or ABS solvent weld body with bottom outlet and 1/2" trap primer connection knock-out plug, stainless steel deckplate, and top assembly.

Where to Buy

Recommended for finished areas
Floor Drain is designed for foot traffic and light-duty applications
Furnished with a PVC or ABS body with an adjustable head assembly, available in nickel bronze or stainless steel

Popular Models

FD2-PV2-SS-CC

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate, Clamp Collar and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV2-ST

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV2-SS

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV3-ST

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV3-ST-CC

PVC Adjustable Floor Drain, 5" Nickel Bronze Head w/Deck Plate, Clamp Collar and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV3-ST-SS-CC

PVC Adjustable Floor Drain, 5" Stainless-Steel Head w/Deck Plate, Clamp Collar and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV2

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV2-ST-SS

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV3-SS

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV2-ST-CC

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate, Collar Clamp and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV2-ST-SS-CC

PVC Adjustable Floor Drain, 5" Stainless-Steel Head w/ Deck Plate, Clamp Collar and 2" x 3" Solvent Weld Outlet

Product Specs

FD2-PV3

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV3-CC

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate, Collar Clamp and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV3-ST-SS

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV3-SS-CC

PVC Adjustable Floor Drain – 5" Stainless-Steel Head with Deck Plate, Clamp Collar and 3" x 4" Solvent Weld Outlet

Product Specs

FD2-PV2-CC

PVC Adjustable Floor Drain – 5" Nickel Bronze Head with Deck Plate, Collar Clamp and 2" x 3" Solvent Weld Outlet

Product Specs
