P1000AXL

Pressure Relief Valve

Retrofit
Zurn Wilkins

The P1000AXL Pressure Relief Valve is utilized on water heating storage vessels for protection against over-temperature or excessive pressure (not for steam service). Primarily used on storage tanks, P1000AXL materials include cast brass or bronze for the main valve body, quality stainless steel 300 series internals, stainless steel springs, and FDA approved, epoxy-coated copper tube probes. Multiple pressure relief settings and inlet/outlet connection options provide easy, ultra versatile installation capabilities, and the P1000AXL assembly shall be used where pressure only relief is required.

  • Eliminates risk of over-pressure of storage tanks
  • Epoxy-coating adds extra protection
  • Pressure relief valve settings of 30, 75, 125, and 150 psi offer versatility
  • CSA Compliance to ANSI Z21.22/CSA 4.4
  • Certified to ASME Section IV by National Board
